Filament Spectrum ASA-X CF10 1.75mm BK 1kg
Spectrum ASA-X CF10 filament
Resistance to outdoor conditions with a beautiful carbon finish
Analysing the feedback from the users of our filament, we have decided to expand the range of materials for outdoor use in conditions...
Description
Spectrum ASA-X CF10 filament
Resistance to outdoor conditions with a beautiful carbon finish
Analysing the feedback from the users of our filament, we have decided to expand the range of materials for outdoor use in conditions of increased exposure to UV radiation, temperature and humidity. ASA, a well-known polymer that is a highly weather-resistant alternative to ABS, has become the base for another composite material, Spectrum ASA-X CF10.
Our paramount objective was to develop a material that would guarantee the printed models consistently high mechanical performance, especially in terms of hardness and stiffness, even under prolonged use in outdoor weather conditions. The result is the creation of Spectrum ASA-X CF10, a composite based on an appropriately selected ASA with carbon fibre filling.
We provide our users with filament that is resistant to external exposure, such as sunlight (UV) and humidity (hydrolysis), with a tensile strength of over 7.5 GPa and a thermal resistance of 101°C. At the same time, Spectrum ASA-X CF10 has low shrinkage and is, unusually for technical materials with comparable properties, easy to print. All of this, combined with a carbon matt surface that effectively masks the layers of the printed models, has made the Spectrum ASA-X CF10 a very popular choice among the 3D printing community.
Advantages of the ASA-X CF10
- HDT thermal resistance - 95°C
- Vicat softening point – 101°C
- excellent resistance to outdoor exposure
- UV resistance
- option to print on desktop printers without a heated chamber
- carbon, matt printed surface
- perfect bonding of the layers
- easy to print compared to classic PLA
Applications:
- functional prototypes
- manufacturing equipment
- manufacture of housings and covers
- manufacture of parts subject to abrasive wear
- manufacturing tools
- components that need high resistance to outdoor exposure
Packaging
Filament is reeled on the neat, transparent spool. Each spool contains information on the type of material, diameter and recommended printing temperature. Filament is vacuum-packed with a moisture absorber. Whole product packed in the original, folied Spectrum Filaments packaging.
Specification
General information
Specification
Technical data
How to print?
Spool dimensions
250
44
140
52
120
Plastic
Transparent
250
44
140
52
80
Cardboard
-
500
55
200
52
240
Plastic
Transparent
750
55
200
52
240
Plastic
Transparent
1000
67
200
52
260
Plastic
Transparent
1000
67
200
52
180
Cardboard
-
2000
100
300
52
600
Plastic
Black
2000
100
300
52
420
Cardboard
-
4500
100
350
52
780
Plastic
Black
8000
167
355
36
1020
Plastic
Black
Each spool is sealed. We recommend storing filaments in a cool (15-25°C) and dry place.
Reviews
Description
Spectrum ASA-X CF10 filament
Resistance to outdoor conditions with a beautiful carbon finish
Analysing the feedback from the users of our filament, we have decided to expand the range of materials for outdoor use in conditions of increased exposure to UV radiation, temperature and humidity. ASA, a well-known polymer that is a highly weather-resistant alternative to ABS, has become the base for another composite material, Spectrum ASA-X CF10.
Our paramount objective was to develop a material that would guarantee the printed models consistently high mechanical performance, especially in terms of hardness and stiffness, even under prolonged use in outdoor weather conditions. The result is the creation of Spectrum ASA-X CF10, a composite based on an appropriately selected ASA with carbon fibre filling.
We provide our users with filament that is resistant to external exposure, such as sunlight (UV) and humidity (hydrolysis), with a tensile strength of over 7.5 GPa and a thermal resistance of 101°C. At the same time, Spectrum ASA-X CF10 has low shrinkage and is, unusually for technical materials with comparable properties, easy to print. All of this, combined with a carbon matt surface that effectively masks the layers of the printed models, has made the Spectrum ASA-X CF10 a very popular choice among the 3D printing community.
Advantages of the ASA-X CF10
- HDT thermal resistance - 95°C
- Vicat softening point – 101°C
- excellent resistance to outdoor exposure
- UV resistance
- option to print on desktop printers without a heated chamber
- carbon, matt printed surface
- perfect bonding of the layers
- easy to print compared to classic PLA
Applications:
- functional prototypes
- manufacturing equipment
- manufacture of housings and covers
- manufacture of parts subject to abrasive wear
- manufacturing tools
- components that need high resistance to outdoor exposure
Packaging
Filament is reeled on the neat, transparent spool. Each spool contains information on the type of material, diameter and recommended printing temperature. Filament is vacuum-packed with a moisture absorber. Whole product packed in the original, folied Spectrum Filaments packaging.
Specification
General information
Specification
Technical data
How to print?
Spool dimensions
| Content [g] | Width [mm] | Outer diameter [mm] | Inner diameter [mm] | Weight empty [g] | Material | Spool color |
|---|---|---|---|---|---|---|
| 250 | 44 | 140 | 52 | 120 | Plastic | Transparent |
| 250 | 44 | 140 | 52 | 80 | Cardboard | - |
| 500 | 55 | 200 | 52 | 240 | Plastic | Transparent |
| 750 | 55 | 200 | 52 | 240 | Plastic | Transparent |
| 1000 | 67 | 200 | 52 | 260 | Plastic | Transparent |
| 1000 | 67 | 200 | 52 | 180 | Cardboard | - |
| 2000 | 100 | 300 | 52 | 600 | Plastic | Black |
| 2000 | 100 | 300 | 52 | 420 | Cardboard | - |
| 4500 | 100 | 350 | 52 | 780 | Plastic | Black |
| 8000 | 167 | 355 | 36 | 1020 | Plastic | Black |
Each spool is sealed. We recommend storing filaments in a cool (15-25°C) and dry place.
